Magnum Melody Step-Thru Electric Bike

The Magnum Melody is a comfort-forward cruiser/commuter electric bike featuring a low step-thru frame design for easy mounting and dismounting. Built on a City Tuned, low-step 6000-series alloy frame, the Melody is designed to accommodate a wide range of riders from 4'11" to 6'3" with a total payload capacity of 330 lbs.

Power comes from a Sutto 500W rear hub motor (750W peak) paired with a fully integrated 48V 15Ah/720Wh battery using Samsung cells, blending seamlessly into the down tube. The motor supports both torque and cadence sensing modes, switchable directly from the display, and the bike is capable of operating as a Class 1, Class 2 (throttle to 20 mph), or Class 3 (pedal assist to 28 mph) e-bike. A thumb throttle is included, and claimed range is up to 55 miles per charge with a 2.5A charger reaching full charge in approximately 6 hours.
